When your production server starts coughing up errors, a DBA does not cry.


RAM is as forgetful as wedding vows, and only an append-only log on disk remembers our sins down to the exact microsecond.


All three heavyweights: MySQL, PostgreSQL, and SQL Server rely on the same core concept (Write-Ahead Logging): carve “I changed this row” into granite first, flush the buffer to disk, and only then pretend the data safely lives in the tables. But the devil, as always, lives in details.


The Cast of Characters

PostgreSQL (WAL, Write-Ahead Log):


PostgreSQL takes an all-in-one approach. It writes continuous, sequential logs divided into immutable 16 MB segment files named with a strict hex numbering scheme. Each record receives a monotonically increasing 64-bit byte offset known as the Log Sequence Number (LSN). WAL records describe how to reproduce the change, not an entire record. It also contains logical transaction state markers (commit/abort). Because of this unified design, PostgreSQL uses the exact same stream of files for:

  • Crash Recovery: Replaying unwritten block changes after a crash.
  • Physical Streaming Replication: Shipping raw byte chunks directly to standby replicas byte-for-byte.
  • Point-in-Time Recovery (PITR): Archiving segments to S3/cold storage to replay history up to a specific timestamp.
  • Logical Decoding: Translating raw WAL records via plugins into JSON or row-level change streams for CDC (Change Data Capture) without needing a secondary log.
  • How replicas impact primary: Replication Slots ensures primary server does not delete and WAL segment that the replica has not yet consumed: if a replica drops off the radar, the slot pins WAL retention, hoard thousands of 16 MB files in pg_wal, and silently eats the primary’s drive until crash.



SQL Server (Transaction Log / LDF):


  • SQL Server manages its transaction log within one or more physical ldf files, structured internally as a circular ring of Virtual Log Files (VLFs). Similarly to Postgres, SQL Server puts both REDO information (how to replay committed work) and UNDO information (how to roll back aborted transactions or live read operations) directly inside this single log stream
  • VLF Management: As transactions write, active VLFs advance circularly. In FULL recovery model, an inactive VLF cannot be reused until a dedicated Transaction Log Backup marks it as truncated. Without regular log backups, in FULL mode, the file expands endlessly until it fills the storage volume.
  • High Availability: Features like Always On Availability Groups ship log blocks directly from the primary's log cache to secondary replicas, hardening them into their own ldf files before hardening them into data files.
  • How replicas impact primary: If a secondary replica falls behind, gets disconnected, or simply stops pulling data, the primary will politely hold onto those log blocks forever .ldf file will quietly grow until it consumes the entire drive.



MySQL (The Split Brain: Redo Log vs. Binlog)


MySQL separates the duties of crash recovery and replication across two independent subsystems:

  • InnoDB Redo Log: A set of circular files managed entirely by the storage engine. Its sole job is ACID crash recovery (replaying dirty pages that never made it from the buffer pool to the tablespace). It is completely unaware of statements, triggers, or higher-level SQL context.
  • Binary Log (The Logical Broadcaster): Managed at the MySQL Server layer (above InnoDB). It records high-level database modifications as events—typically in ROW format (capturing the before/after image of modified rows), though statement-based and mixed formats exist. Binlogs are not used to recover data files after a power loss; they exist exclusively for cross-server replication and Point-in-time recovery.
  • The Coordination (2PC): Because the Redo Log and Binlog are separate files on disk, MySQL implements an internal Two-Phase Commit (2PC) coordinated via XA. When a transaction commits, InnoDB writes a prepare record to the Redo Log, flushes the event to the Binlog, and finally marks the commit in the Redo Log. If the two ever fall out of sync, replication breaks or replicas diverge from the primary.
  • How replicas impact primary: Unlike PostgreSQL and SQL Server, a lagging or dead replica in standard MySQL will not hold back log cleanup on the primary. However, if replicas lag significantly behind, they force the primary to read gigabytes of old binary logs off disk into the OS page cache, causing disk I/O thrashing and evicting hot InnoDB pages from memory.


How log entries look under the microscope:

​MySQL Binlog reads like an audit transcript: "Change row where id=42 from status='active' to 'suspended'." It is logical, structured, and trivially ingestible by Kafka or Debezium.

​Postgres WAL reads like an architect's blueprint: "At file 24576, block 12, mark line pointer 4 dead, insert tuple at line pointer 5." It cares about physical pages and block pointers, reconstructing rows only when fed through a logical decoding plugin.

​SQL Server LDF reads like an accountant’s balance sheet: "Operation MODIFY_ROW on Page 340, Offset 0x1A, Redo Byte [0x73], Undo Byte [0x61]." Everything needed to reconstruct the future or reverse the past is baked directly into the byte stream.


Key Architectural Takeaways


Unity vs. Redundancy: PostgreSQL and SQL Server are engineered around a single source of transactional truth. In contrast, MySQL pays an I/O penalty for its modular history: writing every change to the engine's redo log for survival, and again to the server's binlog for replication. If you kill WAL or the transaction log, the engine refuses to start. In MySQL, InnoDB happily recovers from a crash without the Binlog enabled… you only turn the Binlog on when you need replication or PITR.



Operational Failure Modes: A neglected log in SQL Server causes unbounded log growth that crashes production when the volume fills. In PostgreSQL, a failing archive_command causes WAL files to accumulate until disk exhaustion. In MySQL, misconfigured binlogexpire_logs_auto_purge achieves the exact same catastrophic result.



Downstream Integration (CDC): Logical replication engines (like Debezium or custom CDC scrapers) thrive on MySQL's row-based binlogs because logical row images are trivial to parse compared to re-assembling physical page diffs from a raw transaction stream. PostgreSQL achieves this via logical decoding slots (which reconstruct rows from WAL), while SQL Server relies on Change Tracking or CDC agents querying system tables populated from the transaction log.


The Cost of Commit: Because MySQL splits crash recovery and replication across two distinct logs, every committed transaction pays the overhead of an internal 2PC flush sequence


Congratulations, we’ve unravelled the sacred mystery of Write-Ahead Logs.


Treat your transaction logs well, and they might just let you sleep through the night next time.
